Power System

C7.1

C7.1

C7.1

Highlights
Features & Specs
Photo Gallery

Equipment Highlights

Feature Title Goes Here
Feature Title Goes Here
Feature Title Goes Here

Specs + Downloads

Specs
  • Power Range: 100 - 200 ekW
  • Application: Workboat
  • Emissions: IMO II, IMO III (SCR required) U.S. EPA Tier 3, EU Stage V, China II
  • Configuration: Inline 6, 4-Stroke Cycle Diesel
  • Displacement: 428 in³
  • Aspiration: Turbocharged / Aftercooled
  • Governor: Electronic (A5 ECM)
  • Bore: 4.13 in
  • Stroke: 5.31 in
  • Refill Capacity: Lube Oil System w/oil filter change: 21 L / 5.6 gal
  • Oil Change Interval: 500 hrs
  • Rotation from Flywheel End: Counterclockwise
  • Cooling: Heat exchanger, Seperate Circuit Keel Cooled, Combined Circuit Keel Cooled, Radiator Cooled
  • Length: 76.3 in /1,940 mm
  • Height: 49.7 in / 1,263 mm
  • Engine Dry Weight: 3355 lb / 1,522 kg
  • Frequency: 50 / 60
  • Speed: 1500 rpm / 1800 rpm
  • Width: 38.0 in / 965 mm
Downloads
