C2.2B Genset
Cat C2.2B Marine Generator Set
DESCRIPTION
Cat® C2.2B Marine Generator is designed for advanced functionality. This low-noise, intelligent, and future-ready genset can be sold independently or as part of Cat Marine product solutions. The flexible design ensures seamless installation and single-side servicing for easy maintenance. The Cat C2.2B allows for the integration of multiple power sources, from shore power to batteries, ensuring an uninterrupted power supply. It meets U.S. EPA Tier 3 emissions standards at an engine speed of 1800 rpm, delivering up to 26 KWe of power. The enclosure is 20% smaller compared to the C2.2, offering a more compact footprint without compromising performance.Cat® C2.2B Marine Generator is designed for advanced functionality. This low-noise, intelligent, and future-ready genset can be sold independently or as part of Cat Marine product solutions. The flexible design ensures seamless installation and single-side servicing foreasy maintenance. The Cat C2.2B allows for the integration of multiple power sources, from shore power to batteries, ensuring an uninterrupted power supply. It meets U.S. EPA Tier 3 emissions standards at an engine speed of 1800 rpm, delivering up to 26 KWe of power. The enclosure is 20% smaller compared to the C2.2, offering a more compact footprint without compromising performance.Sound
- Sound enclosure ideal for yachting vessels for quiet operation
Compact size
- Compact size increases installation options
Designed for easy integration and maintenance
- Optimal handed connection panel simplifies engine room plumbing and cuts install time
- Single side serving for easy maintenance
Digital Control System ensures easy operation
- Smart communication ensures seamless connectivity with digital vessel control systems
Over 80 Years of Manufacturing Experience
- For over 80 years, Cat® marine engines have been selected by customers to help them succeed on the water. With over 200,000 engines in operation, and network, our team has experience and dedication to provide reliable solutions, unmatched technology, and support.
Product Support through Global Dealer
- Trained dealer technicians
- Your Cat dealer will listen to your unique needs and find the right solution for your business, budget and goals
- Cat parts and labor warranty Preventative maintenance agreements available for repair
- Standard Equipment
- Optional Equipment
- Specs
- Docs
Standard Equipment
- Standard Equipment
- Sound Attenuation Enclosure
- Digital control panel
- Self-priming fuel lift pump
- 12 or 24 volt system
- Single sided service points
- Water-cooled exhaust manifold
- Wet exhaust
- Single or brushless generator
- Anti-vibration mounts
Optional Equipment
- Optional Equipment
- Double wall fuel injection lines
- Vessel connection Panel
- Siphon break
- AC circuit breaker
- Load share control panel
- Load share junction box
Specs
Overview
Long Name:
Cat C2.2B Marine Generator Set
Name:
C2.2B Genset
Brand:
Cat
Status:
Current
Power Rating
Power Range
16 - 26 ekW
Generator Set Specifications
Frequency
50 / 60
Minimum Rating
16 ekW (18.75 kVA)
Maximum Rating
26 ekW (31.25 kVA)
Speed
1500 / 1800 rpm
Engine Specifications
Emissions
U.S. EPA Tier 3
Configuration
Inline 4, 4- Stroke Cycle Diesel
Rated Engine Speed
1500 / 1800 rpm
Displacement
135 in³ / 2.2 l
Aspiration
Naturally Aspirated / Turbocharged
Governor Type
Electrical Ischronous
Flywheel Housing
SAE No. 04
Bore
3.31 in / 84 mm
Stroke
3.5 in / 100 mm
Refill Capacity
Lube Oil System with Oil Filter Change: 10.6 L (2.8 gal)
Oil Change Interval
500 hours
Rotation from Flywheel End
Counterclockwise
Cooling
Heat Exchanger Cooled
Dimensions & Weights
Length
43.3 in / 1100 mm
Height
740 mm / 29.1 in
Width
24.7 in / 628 mm
Maximum Engine Dry Weight
1036 lb / 480 kg
SEE HOW C2.2B Genset COMPARES AGAINST FREQUENTLY COMPARED PRODUCTS.
Marine Generator Sets
C2.2B Genset
- Brand
- Cat
- Status
- Current
- Power Range
- 16 - 26 ekW
- Frequency
- 50 / 60
- Minimum Rating
- 16 ekW (18.75 kVA)
- Maximum Rating
- 26 ekW (31.25 kVA)
- Emissions
- U.S. EPA Tier 3
- Displacement
- 135 in³ / 2.2 l
- Aspiration
- Naturally Aspirated / Turbocharged
- Governor Type
- Electrical Ischronous
- Bore
- 3.31 in / 84 mm
- Stroke
- 3.5 in / 100 mm
- Length
- 43.3 in / 1100 mm
- Height
- 740 mm / 29.1 in
- Width
- 24.7 in / 628 mm
Selected Model
Marine Generator Sets
C2.2
- Brand
- Caterpillar
- Status
- Current
- Power Range
- 15 - 25 ekW
- Frequency
- 50 / 60
- Minimum Rating
- 15 ekW (15 kVA)
- Maximum Rating
- 25 ekW (25 kVA)
- Emissions
- U.S. EPA Tier 3
- Displacement
- 135 in³ / 2.2 l
- Aspiration
- Naturally Aspirated / Turbocharged
- Governor Type
- Electrical Ischronous
- Bore
- 3.31 in / 84 mm
- Stroke
- 3.5 in / 90 mm
- Length
- 47.9 in / 1,219 mm (open) 50.7 in / 1,290 mm (enclosed)
- Height
- 32.8 in / 835 mm (open) 31.0 in / 775 mm (enclosed)
- Width
- 22.3 in / 567 mm (open) 24.7 in / 628 mm (enclosed)
Marine Generator Sets
C280-12
- Brand
- Caterpillar
- Status
- Current
- Power Range
- 3640 - 3520 ekW
- Frequency
- 50 / 60 Hz
- Minimum Rating
- 3520 ekW (4400 kVA)
- Maximum Rating
- 3640 ekW (4550 kVA)
- Emissions
- EPA Tier 2, IMO II
- Displacement
- 13546 in³ / 222 l
- Aspiration
- Turbocharged-Aftercooled
- Governor Type
- Electronic
- Bore
- 11 in / 280 mm
- Stroke
- 11.8 in / 300 mm
- Length
- 316.5 in / 8040 mm
- Height
- 155 in / 3937 mm
- Width
- 77.2 in / 1961 mm
