Snow Wing
Snow Wing for Motor Graders
Built for operators, the Cat® Snow Wing delivers smooth, controlled snow removal with fast material flow and reliable hydraulics, while simplified linkage, wing‑ready options, and balanced lift points make installation quick, safe, and easy.
DESCRIPTION
Built for operators, the Cat® Snow Wing delivers smooth, controlled snow removal with fast material flow and reliable hydraulics, while simplified linkage, wing‑ready options, and balanced lift points make installation quick, safe, and easy.Safety-Focused
- Optimal operator visibility in working and roading conditions
- Mastless design allows for greater side visibility and door access
- Unobstructed view of wing toe for improved control of material flow
- Blade stows below cab height for shipping and roading
- Robust linkage safety locking pin
Smooth Removal
- Low-friction wing liner sheds material faster for reduced fuel consumption and less steering input
- Hydraulic push pole control for greater angle range and control
- Heel-dampening accumulator for impact cushioning
- Smooth control modulation with no binding
- Industry-leading mastless bench height
Easy Installation
- Simplified linkage and components for faster installation
- Reduced installation and removal time with optional machine wing-ready package
- Balanced lifting points for safe and easy handling
- Retrofittable to current masted snow wing mounts
- Specs
- Docs
Specs
Overview
Long Name:
Snow Wing for Motor Graders
Name:
Snow Wing
Brand:
Cat
Status:
Current
Dimensions
Blade Height, Front
34 in / 863 mm
Length
144 in / 3658 mm
Blade Height, Rear
42.1 in / 1070 mm
Cutting Edge Thickness
0.6 in / 16 mm
Weights
Weight
3660 lb / 1660 kg
Dimensions
Cutting Edge Height
8 in / 203 mm
